RockChip RK3528 Specifications:
| Processor | Rockchip RK3528 | |||
| Market (main) | TV Box | |||
| ISA | ARMv8-A (64-bit) | |||
| Microarchitecture | Cortex-A53 | |||
| Core name | Cortex-A53 | |||
| Family | RK35 Series | |||
| Part number(s), S-Spec |
RK3528
|
|||
| Release date | Q2 2023 | |||
| Lithography | 28 nm HKMG | |||
| Cores | 4 | |||
| Threads | 4 | |||
| Base frequency | 408 MHz | |||
| Turbo frequency | 2.0 GHz | |||
| Details |
4x ARM Cortex-A53
@ 0.408 / 2.016 GHz |
|||
| Cache memory |
256 KB L1 Cache,
512 KB L2 Cache |
|||
| Max memory capacity | 4 GB | |||
| Memory types |
DDR3(L)/LPDDR3,
DDR4/LPDDR4, DDR3-2133/DDR3L-2133/LPDDR3-2133, DDR4-2400/LPDDR4-2400 |
|||
| Max PCIe lanes | 4 | |||
| TDP |
5 W
|
|||
| GPU integrated graphics | ARM Mali-450 MP2 | |||
| GPU execution units | 2 | |||
| GPU shading units | 32 | |||
| GPU base clock | 300 MHz | |||
| GPU boost clock | 750 MHz | |||
| GPU FP32 floating point | 23.8 GFLOPS | |||
| Additional graphics features |
OpenGL ES 2.0,
2D Graphic Engine, HDR10, Video Format: |
|||
| Socket(s) | SoC | |||
| Drystone MIPS | 18,400 DMIPS | |||
| Crypto engine |
Crypto Engine,
AES, NEON, FPU, SHA-1, SHA-256/224, MD5, SM3, HMAC, AES-128, AES-192, AES-256, DES, TDES, SM2/SM3/SM4, RSA-4096 |
|||
| Security |
TrustZone, RNG,
Firewall Engine, Watch Dog |
|||
| Max display resolution |
8K@25fps; 4K@60fps
|
|||
| Video decoding |
H.265, HEVC, H.264, AVC, AVS2,
4K@60fps, 8K@25fps, MPEG-1, MPEG-2, MPEG-3, MPEG-4, 1080p@60fps, VC-1, 1080p@60fps, H.263, 576p@60fps, JPEG Decoder |
|||
| Video encoding |
H.265, H.264,
1080p@60fps, JPEG Encoder |
|||
| Modem |
10/100M Ethernet MAC+PHY,
1000M Ethernet MAC |
|||
| Connectivity |
USB 3.0 Gen 1 (5Gbps),
USB 2.0 (480Mbps), HDMI 2.0b, HDCP 2.2, eMMC, SD/MMC, PCIe2.1, DMAC, I2S, SPIx2, PWMx8, SPDIF, SDIO3.0x2, UARTx8, I2Cx8, GPIO, TDM (8CH), PCM (2CH), PDM (8CH) |
|||
| Wi-Fi |
Wi-Fi 6 802.11b/g/n/ac/ax
|
|||
| Bluetooth |
Bluetooth 5.0
|
|||
| Audio |
A/V Output, DAC, Line-Out,
Mono, Stereo, 8-96KHz, Audio Format: |
|||
| Additional features |
4K Ultra HD Resolution,
Widevine L1, TSADC, SARADC, Picture Format: |
|||
| AnTuTu | 69,421 | |||
| PassMark single thread | 434 | |||
| PassMark CPU Mark | 889 | |||
| (Android) Geekbench 4 single core |
760 | |||
| (Android) Geekbench 4 multi-core |
1,855 | |||
| (Android) Geekbench 5 single core |
140 | |||
| (Android) Geekbench 5 multi-core |
407 | |||
| (Android) Geekbench 6 single core |
160 | |||
| (Android) Geekbench 6 multi-core |
398 | |||
| (SGEMM) GFLOPS Performance |
11.8 GFLOPS | |||
| (Multi-core / watt performance) Performance / watt ratio |
371 pts / W |
