X98H Pro

Android 12 TV box X98H Pro with Allwinner H618 Quad Core Processor 2GB 4GB DDR 16GB 32GB 64GB eMMC 2.4G 5G dual band WiFi 6 Bluetooth 5.0 6K 30FPS video or TV playing android 12 OS.

Android 12 TV box X98H Pro with Allwinner H618 Quad Core Processor 2GB 4GB DDR 16GB 32GB 64GB eMMC 2.4G 5G dual band WiFi 6 Bluetooth 5.0 6K 30FPS video or TV playing android 12 OS.

























X98H Pro Product Specifications:





Product Model
X98H Pro
Project Status
M.P
Hardware Specs:
CPU
Chipset
Allwinner H618
Architecture
Quad core ARM Cortex A53
GPU
Chipset
Mali G31 MP2
RAM
Capacity
2GB /4GB
ROM
Capacity
16GB /32GB /64GB
External storage
USB Storage Devices
Supported
Software Specs:
Operating system
OS Version
Android 12
Language
Multi-Language
Multimedia
Video
Video Decoder:
H265 Main10@L5.1 decoder up to 4K@60fps or 6K@30fps
VP9 Profile 2 decoder up to 4K @ 60fps
AVS2 Jizhun 10bit decoder up to 4K @ 60fps
H.264 BP/MP/HP@L4.2 decoder up to 4K@30fps
Multi-format 1080p @ 60fps video playback formats ,including H.264 BP/MP/HP, H 263 BP , VP8 , MPEG-1 MP/HL ,MPEG-2 MP/HL, MPEG-4
SP/ASP @ L5, AVS +/AVS JizhunWMV9/VC1,etc
Video encoder:
H.264 BP/MP/ HP encoder up to 4K@25fps or 1080p @ 60fps JPEG snapshot performance of 1080p @ 60fps
Audio
MP3, AAC, WMA, FLAC, Ogg.
HD JPEG; BMP; GIF; PNG; TIF
Network service
Wi-Fi
Type
IEEE802. a/b/g/n/ac/ax (optional)
Frequency
2 4GHZ ~ 5.8GHZ WiFi 6
Antenna Type
Inside antennas
BT
BT
BT5.0+
Interface
Charge
DC connector
DC 5V- 2A
Video output
HDMI
1* 4K 2K Output, HDMI 2.0A
AV OUT
3.5mm Earphone
1* 480u576i standard definition output
Video input
HDMI IN
1* HDMI 1.4 RX input
OPTCAL
/
1 * SPDIF
Ethernet
Ethernet
1 *100M LAN
TF Card
External memory
1* TF Card
USB port
USB Host
3 * USB 2.0
Switch
KEY
1* Switch HDMI IN or HDMI OUT
X98H Pro android 12 TV box Appearance:
Body Material
Plastic
Color
Black
Size
135x90x23(mm)
Weight
0.15Kg
Cerifications(For Unit)
Standard
CE
/
RoHS
/
Others
Optional
/
Package contents
Shipping Info
User manual
*1
Gift Box Dimension(mm)
185*145*54mm
Gift Box
*1
Carton Size(mm)
390*300*290mm
Remote control
*1
Qty Per Carton(pcs)
20pcs
HDMI external cable
*1
Gift Box.G.W(gs)
0.394Kg
Power adapter
*1
Export carton (G.W.)(kgs)
8.88Kg
